GCM21BR71H224KA37 Datasheet by Murata Electronics

muRata Capacitor Data Sheet ,, ”7" AEc- 125 A Allmlinn muHata Mm "Mach-mg 00., Lid.
L size 2.0 ±0.15mm
W size 1.25 ±0.15mm
T size 1.25 ±0.15mm
External terminal width e 0.2 to 0.7mm
Distance between external terminals g 0.7mm min.
Size code in inch(mm) 0805 (2012M)
Packaging Specifications Minimum quantity
Lφ180mm Embossed taping 3000
Kφ330mm Embossed taping 10000
Mass (typ.)
1 piece 17.0mg
φ180mm Reel 102g
GCM21BR71H224KA37# “#” indicates a package specification code.
< List of part numbers with package codes >
GCM21BR71H224KA37L , GCM21BR71H224KA37K
Capacitance 0.22µF ±10%
Rated voltage 50Vdc
Temperature characteristics (complied standard) X7R(EIA)
Capacitance change rate ±15.0%
Temperature range of temperature characteristics -55 to 125℃
Operating temperature range -55 to 125℃
Shape References
Specifications
Last updated: 2019/09/19
1 of 2
1.This datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. Therefore, it’s specifications are subject to change or our products in it may be discontinued
without advance notice. Please check with our sales representatives or product engineers before ordering.
2.This datasheet has only typical specifications because there is no space for detailed specifications.
Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
URL : https://www.murata.com/
Frequency characteristiclll IOk 1k 100 10 lwedance [ohm] 1 10m 100 1k 10k 100k 1! 1M 10“ 106 Frequencvlflz] lsmmmmzzmn ucov, [Ed-KC DC bias characteristics 0. 24 0.22 E \ ‘3‘ 0.2 2 50. 18 "2 £0. 16 0. 14 0 10 20 30 40 50 DC Bius[V] .mmnmzzmn capacimc- 25 cause, ACI ons 1enuetature charncteristics 0.222 ’ \ 0. 22 E :0 m / 2 50. 216 "2 30. 214 \ 0 212 0 21 ~80 40 0 40 80 I20 160 TamernturemsC] lsmzmmmzuun capacitnncl nco 0v, Acl «Vms A intuition ”unfit" Mum Madam-mg 00., Lu Frequency Characteristicfl _a§ lies i stance [ohm] 1m 100 1k 10k 100k 1' 1M 10“ 1G 106 Frequency [Hz] lsmmmmzzmn ucov, zsa-xc AC antage characteristics 0. 216 0 2M 0 0. 4 0 8 1,2 1. 6 2 Ac VoltagelVrms] .nmmnmzzmn capacitnncl noov. 25 oaegc Ian Rise fran ripple Characteristics 100 10 ImeraturewezC] 1 0.4 0.8 12 1.6 2 24 2.8 mrrentflrms] aclziammzumnlanoknz laookuz .ilflz
Chart of characteristic data (The charts below may show another part number which shares its characteristics.)
Last updated: 2019/09/19
2 of 2
