ms» Lg!“ DESD5VOU1 BB 203® ~ Hem Devwce Schemahc
DESD5V0U1BB
Document number: DS35944 Rev. 4 - 2
1 of 5
www.diodes.com
April 2015
© Diodes Incorporated
DESD5V0U1BB
ADVANCE INFO R MA T I O N
ADVANCE INFO R MA T I O N
LOW CAPACITANCE BIDIRECTIONAL TVS DIODE
Features
Provides ESD Protection per IEC 61000-4-2 Standard:
Contact ±10kV
1 Channel of ESD Protection
High Peak Pulse Current per IEC 61000-4-5 Standard
Low Channel Input Capacitance
Typically used in Cellular Handsets, Portable Electronics,
Communication Systems, Computers and Peripherals
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Ordering Information (Note 4)
Product
Compliance
Marking
Reel Size (inches)
Tape Width (mm)
Quantity per Reel
DESD5V0U1BB-7 (Note 5)
Standard
7
8
3,000/Tape & Reel
Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
5. Dispensed every other cavity of the carrier tape.
Marking Information
K /
K
Device Schematic
Top View
= Product Type Marking Code
12
SOD523
K /
K
SOD523
m5” DESstou1BB PP
DESD5V0U1BB
Document number: DS35944 Rev. 4 - 2
2 of 5
www.diodes.com
April 2015
© Diodes Incorporated
DESD5V0U1BB
ADVANCE INFO R MA T I O N
ADVANCE INFO R MA T I O N
Maximum Ratings (@TA = +25°C unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Conditions
Peak Pulse Current
IPP
3
A
8/20µs, per Figure 3
ESD Protection Contact Discharge
VESD_Contact
±10
kV
IEC 61000-4-2 Standard
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Package Power Dissipation (Note 6)
PD
250
mW
Thermal Resistance, Junction to Ambient (Note 6)
RJA
500
°C/W
Operating and Storage Temperature Range
TJ, TSTG
-65 to +150
C
Electrical Characteristics @TA = 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Conditions
Reverse Standoff Voltage
VRWM
-
-
5
V
-
Channel Leakage Current (Note 7)
IRM
-
5
100
nA
VRWM = 5V
Clamping Voltage
VCL
-
7.2
-
V
IPP = 3A, tp = 8/20µs
Breakdown Voltage
VBR
5.5
7
9.5
V
IR = 5mA
Differential Resistance
RDIF
-
-
100
IR = 1mA
Dynamic Impedance
Rdyn
-
0.3
-
TLP, 20A, tp = 100 ns
Channel Input Capacitance
CT
-
2.9
-
pF
VR = 0V, f = 1MHz
-
1.9
-
VR = 5V, f = 1MHz
Notes: 6. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
http://www.diodes.com.
7. Short duration pulse test used to minimize self-heating effect.
0
25
50
75
100
125
150
175
200
225
250
275
300
025 50 75 100 125 150 175
PD, POWER DISSIPATION(mW)
TA,AMBIENT TEMPERATURE(C)
Figure 1. Power Derating Curve
0
25
50
75
100
025 50 75 100 125 150 175 200
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
TA,AMBIENT TEMPERATURE(C)
Figure 2. Pulse Derating Curve
Voltage (V) 100 DESD5VOU1 BB mm m VFINZ +akv Cunlact Dischzvgs Volta ge (V) 100 8 S N a 50 100 150 Time (ns) 50 Time (nsD 100 150
DESD5V0U1BB
Document number: DS35944 Rev. 4 - 2
3 of 5
www.diodes.com
April 2015
© Diodes Incorporated
DESD5V0U1BB
ADVANCE INFO R MA T I O N
ADVANCE INFO R MA T I O N
5.0
5.5
6.0
6.5
7.0
7.5
11.5 22.5 33.5
VC,CLAMPING VOLTAGE (V)
CURRENT(A)
Figure 3. Clamping Voltage Characteristic
IEC61000-4-5
(Lighting)
1.8
2.0
2.2
2.4
2.6
2.8
3.0
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
Cd (pF)
VR (V)
Figure 4. Input Capacitance vs. Input Voltage
f=1MHz, Tamb = 25℃
0
2
4
6
8
10
12
14
16
18
20
22
24
0 2 4 6 8 10 12
Current from I/O to Vss (A)
Voltage from I/O to Vss(V)
Figure 5. Current vs. Voltage
I/O to Vss, Tj initial = 25℃
0
1
2
3
4
5
6
7
8
9
-30 -20 -10 0 10 20 30 40 50 60 70
CLAMPING VOLTAGE,CURRENT (V,A)
t,TIME（us）
Figure 6. Waveform of Clamping Voltage,Current vs.
Time(8/20us,I/O to Vss)
Ampere
Volt
Figure 7 ESD response to IEC 61000-4-2
Figure 8 ESD response to IEC 61000-4-2
PIN2 to VPIN1, +8kV Contact Discharge
PIN1 to VPIN2, +8kV Contact Discharge
DESD5VOU1 BB H
DESD5V0U1BB
Document number: DS35944 Rev. 4 - 2
4 of 5
www.diodes.com
April 2015
© Diodes Incorporated
DESD5V0U1BB
ADVANC E INF O R M A TION
ADVANC E INF O R M A TION
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
SOD523
Dim
Min
Max
A
0.25
0.35
B
0.70
0.90
C
1.50
1.70
H
1.10
1.30
K
0.55
0.65
L
0.10
0.30
M
0.10
0.12
All Dimensions in mm
Dimensions
Value (in mm)
G
0.80
X
0.60
X1
2.00
Y
0.70
H
C
A
BK
M
L
X1
Y
X
G
m5” DESstou1BB
