MCR-S-...-DCI
Data sheet
1Description
The MCR-S-...-DCI current transducers offer users the
option of ordering a preconfigured device, configuring the
device themselves via DIP switches or programming it with
MCR/PI-CONF-WIN configuration software
(Order No. 2814799).
The MCR-S-1-5-UI-DCI module provides not only the
standard 1 A and 5 A input signals, but also the option of
setting current ranges of 0 ... 0.2 A to 0 ... 11 A
progressively.
With a measuring range of 0 ... 9.5 A to 0 ... 55 A, the
MCR-S-10-50-UI-DCI is ideal for measuring higher motor
currents.
DC, AC, and distorted currents can be equally well
measured.
In addition to an analog output, these current transducers
also have an optional relay and transistor output, e.g., for
alarm monitoring.
When ordering, the desired configuration to which the
device is to be adapted must be specified (see order key on
page 6 and page 9).
Features
– Progressive adjustment of measuring range
– True r.m.s. value measurement
– 3-way electrical isolation according to EN 61010
– With optional relay and transistor output
– 22.5 mm ME housing
POWER
U,I
IN OUT
I
FL
Power
Observe the safety notes on page 11.
Make sure you always use the latest documentation.
It can be downloaded from the product at www.phoenixcontact.net/catalog.
This data sheet is valid for the products listed on the following page:
Current transducer up to 55 A,
programmable and configurable
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 2
2Table of contents
1 Description.................................................................................................................................. 1
2 Table of contents ........................................................................................................................ 2
3 Ordering data.............................................................................................................................. 3
4 Technical data ............................................................................................................................ 4
4.1 Technical data for MCR-S-1-5-UI(-SW)-DCI(-NC) (measuring range 0 A ... 0.2 A to 0 A ... 11 A) .................. 4
4.2 Technical data for MCR-S-10-50-UI(-SW)-DCI(-NC) (measuring range 0 A ... 9.5 A to 0 A ... 55 A) .............. 7
5 Design .......................................................................................................................................10
6 Installation and startup...............................................................................................................11
6.1 Safety notes ................................................................................................................................................. 11
6.2 Method of operation ..................................................................................................................................... 11
6.3 Electrical connection .................................................................................................................................... 11
6.4 Startup.......................................................................................................................................................... 12
6.5 Configuration flowchart................................................................................................................................. 12
7 Software package (adapter) ......................................................................................................18
8 Application examples.................................................................................................................19
8.1 Motor current measurement ......................................................................................................................... 19
8.2 Acquisition of motor current peak loads........................................................................................................ 19
8.3 Lighting monitoring....................................................................................................................................... 19
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 3
3Ordering data
MCR current transducer, for measuring AC, DC, and distorted Currents
Description Type Order No. Pcs./Pkt.
Measuring range 0 A ... 0.2 A to 0 A ... 11 A
Configured, with screw connection MCR-S-1-5-UI-DCI12814634 1
Unconfigured, with screw connection MCR-S-1-5-UI-DCI-NC 2814715 1
Measuring range 0 A ... 0.2 A to 0 A ... 11 A, with relay and transistor output
Configured, with screw connection MCR-S-1-5-UI-SW-DCI12814650 1
Unconfigured, with screw connection MCR-S-1-5-UI-SW-DCI-NC 2814731 1
Measuring range 0 A ... 9.5 A to 0 A ... 55 A
Configured, with through connection MCR-S-10-50-UI-DCI12814647 1
Unconfigured, with through connection MCR-S10-50-UI-DCI-NC 2814728 1
Measuring range 0 A ... 9.5 A to 0 A ... 55 A, with relay and transistor switching output
Configured, with through connection MCR-S-10-50-UI-SW-DCI12814663 1
Unconfigured, with through connection MCR-S10-50-UI-SW-DCI-NC 2814744 1
1If no further details are given as to the configuration, the device is supplied in the standard configuration (see order key on page page 6 and page 9).
Accessories
Description Type Order No. Pcs./Pkt.
Configuration software MCR/PI-CONF-WIN 2814799 1
Software adapter cable (stereo jack connector/25-pos. D-SUB) 1.2 m MCR-TTL/RS232-E 2814388 1
Adapter cable, 9-pos. D-SUB female connector to 25-pos. D-SUB male
connector
PSM-KAD 9 SUB 25/BS 2761295 1
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 4
4 Technical data
4.1 Technical data for MCR-S-1-5-UI(-SW)-DCI(-NC) (measuring range 0 A ... 0.2 A to 0 A ... 11 A)
Measuring input MCR-S-1-5-UI-DCI
(-NC)
MCR-S-1-5-UI-SW-DCI
(-NC)
Input current (AC, DC or distorted currents) 0 A ... 11 A
Frequency range 15 Hz ... 400 Hz
Connection method Screw terminal block 2.5 mm2
Overload capacity, continuous 2 x INom
Surge strength for 1 s 20 x INom (100 A, maximum)
Output MCR-S-1-5-UI-DCI
(-NC)
MCR-S-1-5-UI-SW-DCI
(-NC)
Output current/load 0(4) mA ... 20 mA, 20 mA ... 0(4) mA / < 500 Ω
Output voltage/load 0(2) V ... 10 V, 10 V ... 0(2) V / > 10 kΩ
0(1) V ... 5 V, 5 V ... 0(1) V / > 10 kΩ
±10 V, ± 5 V / > 10 kΩ
Switching output MCR-S-1-5-UI-DCI
(-NC)
MCR-S-1-5-UI-SW-DCI
(-NC)
Relay Output
Contact material
Max. switching voltage
Continuous current load capacity
–1 PDT
AgSnO2, hard gold-plated
30 V AC / 36 V DC
50 mA
Transistor output
Maximum transistor current
Output voltage during event
–PNP output
80 mA (not short-circuit-proof)
1 V under supply voltage
Threshold setting –1 % ... 110 %
Suppression time –0.1 s ... 20 s
Threshold value switch status indicator –Yellow LED
If the specified maximum values are exceeded, the gold coating will be damaged. In subsequent operation, the following maximum switching
voltages and currents apply: 250 V AC/DC; 2A.
General data MCR-S-1-5-UI-DCI
(-NC)
MCR-S-1-5-UI-SW-DCI
(-NC)
Supply voltage 20 V DC ... 30 V DC
Current consumption (without load) Approximately 40 mA Approximately 50 mA
Transmission error of nominal value under nominal conditions:
Measuring range nominal value:
operate threshold from measuring range nominal value
Input signal form:
Measurement mode:
Ambient temperature:
Supply voltage:
< 0.5 %
0 A ... 1 A/5 A/10 A
2 %
50 Hz - sine
true r.m.s. value
23 °C
24 V DC
Temperature coefficient < 0.025%/K
Measuring rate 40 measurements/s with DC
5 measurements/s with AC
Step response (10% ... 90 %) 40 ms with DC
330 ms with DC
Safe isolation according to EN 50178, EN 61010
Input/output (analog), input/output (relay),
input/output (transistor), input/supply
300 V AC to ground
(suitable for measuring in 400 V AC three-phase networks)
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 5
Test voltage
Input/output (analog), input/output (relay),
input/output (transistor), input/supply
Output (analog)/output (relay),
output (relay)/output (transistor)
Output (analog)/output (transistor), output (analog)/supply
4 kV, 50 Hz, 1 min.
4 kV, 50 Hz, 1 min.
500 V, 50 Hz, 1 min.
Ambient temperature (operation) -20 °C ... 60 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Module warm-up time ≥ 2 min.
Supply voltage status indicator Green LED
Degree of protection IP20
Mounting position Any
Mounting Any
Dimensions (W x H x D) 22.5 mm x 99 mm x 114.5 mm
Housing material Polyamide PA, non-reinforced
General data (continued) MCR-S-1-5-UI-DCI
(-NC)
MCR-S-1-5-UI-SW-DCI
(-NC)
Approvals
CE c
UL UPROCESS CONTROL EQUIPMENT FOR HAZARDOUS
LOCATIONS 31ZN
Cl. I Zn. 2, AEx nC IIC T6 / Ex nC IIC T6
Cl. I Div. 2, Groups A, B, C and D
A) This equipment is suitable for use in Class I, Division 2,
Groups A, B, C and D or non-hazardous locations only.
B) Warning - explosion hazard - substitution of components may impair
suitability for Class 1, Division 2.
C) Warning - explosion hazard - do not disconnect equipment unless
power has been switched off or the area is known to be non-hazardous.
Conformance with EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC
Noise immunity test according to EN 61000-6-21
Electrostatic discharge (ESD) EN 61000-4-2 Criterion B28 kV air discharge
Electromagnetic HF field EN 61000-4-3 Criterion A310 V/m
Fast transients (burst)
Input/output/power supply
EN 61000-4-4 Criterion B2
2 kV / 5 kHz
Surge current load (surge)
Input/output
Supply
EN 61000-4-5 Criterion B2
2 kV / 42 Ω
1 kV / 2 Ω
Conducted interference
Input/output/power supply
EN 61000-4-6 Criterion A3
10 V
Noise emission test according to EN 61000-6-4
Noise emission of housing EN 550114Class A5
1EN 61000 corresponds to IEC 61000
2Criterion B: Temporary adverse effects on the operating behavior, which the device corrects automatically.
3Criterion A: Normal operating behavior within the specified limits.
4EN 55011 corresponds to CISPR11
5Class A: Industrial application, without special installation measures.
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 6
Order Key for the MCR-S-1-5-UI(-SW)-DCI Current Transducer
If incorrect or no customer order information is given, the standard configuration is delivered (shown as an example in the
ordering key).
Order No. Measuring Range Start
Value
Measuring Range Final
Value Output signal
2814634 / 0.00 / 5.00 / OUT01
MCR-S-1-5-UI-DCI 0 A ... 7.5 A 0.2 A ... 11 A OUT01 = 0 mA ... 20 mA
0.00 = 0 A 5.00 = 5 A OUT02 = 4 mA ... 20 mA
OUT03 = 0 V ... 10 V
OUT04 = 2 V ... 10 V
OUT05 = 0 V ... 5 V
OUT06 = 1 V ... 5 V
OUT13 = -5 V ... +5 V
OUT14 = -10 V ... +10 V
Order No. Measuring
RangeStart
Value
Measuring
Range Final
Value
Output signal Threshold
value
Suppression
time
Switching behavior of relay and
transistor
2814650 / 0.00 / 5.00 / OUT01 / 50 / 3.0 / A / O
MCR-S-1-5-
UI-SWI-DCI
0 A ... 7.5 A 0.2 A ... 11 A OUT01 = 0 mA ... 20 mA 1 % ... 110 % 0.1 s ... 20 s A = operating
current-
controlled
O = Above
0.00 = 0 A 5.00 = 5 A OUT02 = 4 mA ... 20 mA
50 = 50 % of the
set measuring
range final value
(here: 2.5 A)
3.0 = 3 s
OUT03 = 0 V ... 10 V R = Closed
circuit current-
controlled
U = Below
OUT04 = 2 V ... 10 V
OUT05 = 0 V ... 5 V
OUT06 = 1 V ... 5 V
OUT13 = -5 V ... +5 V
OUT14 = -10 V ... +10 V
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 7
4.2 Technical data for MCR-S-10-50-UI(-SW)-DCI(-NC) (measuring range 0 A ... 9.5 A to 0 A ... 55 A)
Measuring input MCR-S-10-50-UI-DCI
(-NC)
MCR-S-10-50-UI-SW-DCI
(-NC)
Input current (AC, DC or distorted currents) 0 A ... 55 A (freely adjustable)
Frequency range 15 Hz ... 400 Hz
Connection method Through connection 10.5 mm ∅
Overload capacity, continuous Depends on the conductor
Current carrying capacity for 1 s Depends on the conductor
Output MCR-S-10-50-UI-DCI
(-NC)
MCR-S-10-50-UI-SW-DCI
(-NC)
Output current/load 0(4) mA ... 20 mA, 20 mA ... 0(4) mA / < 500 Ω
Output voltage/load 0(2) V ... 10 V, 10 V ... 0(2) V / > 10 kΩ
0(1) V ... 5 V, 5 V ... 0(1) V / > 10 kΩ
±10 V, ± 5 V / > 10 kΩ
Switching output MCR-S-10-50-UI-DCI
(-NC)
MCR-S-10-50-UI-SW-DCI
(-NC)
Relay Output
Contact material
Max. switching voltage
Continuous current load capacity
–1 PDT
AgSnO2, hard gold-plated
30 V AC / 36 V DC
50 mA
Transistor output
Maximum transistor current
Output voltage during event
–PNP output
80 mA (not short-circuit-proof)
1 V under supply voltage
Threshold setting –1 % ... 110 %
Suppression time –0.1 s ... 20 s
Threshold value switch status indicator –Yellow LED
If the specified maximum values are exceeded, the gold coating will be damaged. In subsequent operation, the following maximum
switchingvoltages and currents apply: 250 V AC/DC; 2A.
General data MCR-S-10-50-UI-DCI
(-NC)
MCR-S-10-50-UI-SW-DCI
(-NC)
Supply voltage: 20 V DC ... 30 V DC
Current consumption (without load) Approximately 40 mA Approximately 50 mA
Current consumption (with transistor switching output: max. 80 mA) Approximately 120 mA Approximately 130 mA
Transmission error of nominal value under nominal conditions:
Measuring range nominal value:
operate threshold from measuring range nominal value
Input signal form:
Measurement mode:
Ambient temperature:
Supply voltage:
< 0.5 %
0 A ... 50 A
0.8 %
50 Hz - sine
true r.m.s. value
23 °C
24 V DC
Temperature coefficient < 0.025%/K
Measuring rate 40 measurements/s with DC
5 measurements/s with AC
Step response (10% ... 90 %) 40 ms with DC
330 ms with AC
Safe isolation according to EN 50178, EN 61010
Input/output (analog), input/output (relay),
input/output (transistor), input/supply
300 V AC to ground
(suitable for measuring in 400 V AC three-phase networks)
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 8
Test voltage
Input/output (analog), input/output (relay),
input/output (transistor), input/supply
Output (analog)/output (relay),
output (relay)/output (transistor)
Output (analog)/output (transistor), output (analog)/supply
4 kV, 50 Hz, 1 min.
4 kV, 50 Hz, 1 min.
500 V, 50 Hz, 1 min.
Ambient temperature (operation) -20 °C ... 60 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Module warm-up time ≥ 2 min.
Supply voltage status indicator Green LED
Degree of protection IP20
Mounting position Any
Mounting Any
Dimensions (W x H x D) 22.5 mm x 99 mm x 114.5 mm
Housing material Polyamide PA, non-reinforced
General data (continued) MCR-S-10-50-UI-DCI
(-NC)
MCR-S-10-50-UI-SW-DCI
(-NC)
Approvals
CE c
UL UPROCESS CONTROL EQUIPMENT FOR HAZARDOUS
LOCATIONS 31ZN
Cl. I, Zn. 2, AEx nC IIC T6 / Ex nC IIC T6
Cl. I Div. 2, Groups A, B, C and D
A) This equipment is suitable for use in Class I, Division 2,
Groups A, B, C and D or non-hazardous locations only.
B) Warning - explosion hazard - substitution of components may impair
suitability for Class 1, Division 2.
C) Warning - explosion hazard - do not disconnect equipment unless
power has been switched off or the area is known to be non-hazardous.
Conformance with EMC Directive 2004/108/EG and Low Voltage Directive 2006/95/EG
Noise immunity test according to EN 61000-6-21
Electrostatic discharge (ESD) EN 61000-4-2 Criterion B28 kV air discharge
Electromagnetic HF field EN 61000-4-3 Criterion A310 V/m
Fast transients (burst)
Input/output/power supply
EN 61000-4-4 Criterion B2
2 kV / 5 kHz
Surge current load (surge)
Input/output
Supply
EN 61000-4-5 Criterion B2
2 kV / 42 Ω
1 kV / 2 Ω
Conducted interference
Input/output/power supply
EN 61000-4-6 Criterion A3
10 V
Noise emission test according to EN 61000-6-4
Noise emission of housing EN 550114Class A5
1EN 61000 corresponds to IEC 61000
2Criterion B: Temporary adverse effects on the operating behavior, which the device corrects automatically.
3Criterion A: Normal operating behavior within the specified limits.
4EN 55011 corresponds to CISPR11
5Class A: Industrial application, without special installation measures.
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 9
Order Key for the MCR-S-10-50-UI(-SW)-DCI current transducer
If incorrect or no customer order information is given, the standard configuration is delivered (shown as an example in the
ordering key).
Order No. Measuring range start value Measuring range final value Output signal
2814647 / 0.0 / 50.0 / OUT01
MCR-S-10-50-UI-DCI 0 A ... 37.5 A 9.5 A ... 55 A OUT01 = 0 mA ... 20 mA
0.0 = 0 A 50.0 = 50 A OUT02 = 4 mA ... 20 mA
OUT03 = 0 V ... 10 V
OUT04 = 2 V ... 10 V
OUT05 = 0 V ... 5 V
OUT06 = 1 V ... 5 V
OUT13 = -5 V ... +5 V
OUT14 = -10 V ... +10 V
Order No. Measuring
rangestart
value
Measuring
range final
value
Output signal Threshold
value
Suppression
time
Switching behavior of relay and
transistor
2814663 / 0.0 / 50.0 / OUT01 / 50 / 3.0 / A / O
MCR-S-10-50
-UI-SWI-DCI
0 A ... 37.5 A 9.5 A ... 55 A OUT01 = 0 mA ... 20 mA 1 % ... 110 % 0.1 s ... 20 s A = Operating
current-
controlled
O = Above
0.0 = 0 A 50.0 = 50 A OUT02 = 4 mA ... 20 mA
50 = 50 % of the
set measuring
range final value
(here: 25 A)
3.0 = 3 s
OUT03 = 0 V ... 10 V R = Closed
circuit current-
controlled
U = Below
OUT04 = 2 V ... 10 V
OUT05 = 0 V ... 5 V
OUT06 = 1 V ... 5 V
OUT13 = -5 V ... +5 V
OUT14 = -10 V ... +10 V
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 10
5Design
Figure 1 Structure using the example of the MCR-S-...-UI-SW-DCI(-NC) current transducer with relay and transistor
output
1Metal lock for mounting on the DIN rail
2Upper part of housing slides open for DIP switch setting
3Programming interface
4TIME potentiometer for threshold value suppression
time (only for MCR-S-...-UI-SW-DCI(-NC))
5"SW" LED (yellow): Threshold value switch
(only for MCR-S-...-UI-SW-DCI(-NC))
6"POWER" LED (green): Supply voltage
7ZERO/SPAN potentiometer
8Threshold value potentiometer
(only for MCR-S-...-UI-SW-DCI(-NC))
9Cable feed-through
(only for MCR-S-10-50-UI(-SW)-DCI(-NC))
9101112
5678
1234
POWER
SW ZERO
SPAN
SW
MCR-S-1-5-UI-SW-DCI
RELAIS OUT
TIME
20 0
sec
OUT
IN
12 1114 NC
10A 5A 1A
+24V GND1SW GND1
UGND2 GND2
MCR-S-1-5-UI-SW-DCI
Art.-Nr.: 28 14 65 0
APPROBATIONEN / APPROVALS
910 1112
1234
POWER
SW ZERO
SPAN
SW
MCR-S-10-50-UI-SW-DCI
RELAIS OUT
TIME
20 0
sec
OUT
12 1114 NC
+24V GND1SW GND1
UGND2GND2
MCR-S-10-50-UI-SW-DCI
Art.-Nr.: 28 14 66 3
APPROBATIONEN / APPROVALS
1
MCR-S-1-5-UI-SW-DCI MCR-S-10-50-UI-SW-DCI
2
4
7
8
6
3
5
1
2
4
7
8
6
3
9
5
The potentiometers on the front should only be
adjusted using a screwdriver, which is safely
isolated from the voltage at the input.
999
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 11
6 Installation and startup
6.1 Safety notes
6.2 Method of operation
Connection to the input terminal blocks (MCR-S-1-5-...-DCI)
or passing the live conductor through the current transducer
(MCR-S-10-50-...-DCI) induces a magnetic flux in the strip-
wound core. The magnetic flux density is measured using a
Hall sensor and converted proportionally from the input
current to a voltage (Hall voltage). A subsequent true r.m.s.
value converter enables DC, AC, and distorted currents to
be measured. The signal is amplified for further processing
and made available as a proportional analog signal at the
output.
6.3 Electrical connection
Pin assignment
During operation, certain parts of this electric
measuring transducer may carry hazardous
voltages. Disregarding this warning may
result in serious personal injury or damage to
property.
MCR-S-...-DCI Modules must only be installed
and started by qualified personnel.
Qualified personnel are people who, because
of their education, experience and
instruction and their knowledge of relevant
standards, regulations, accident prevention
and service conditions, have been
authorized by those responsible for the
safety of the plant, to carry out any required
operations and who are able to recognize
and avoid any possible dangers.
The transducer must not be started up when
the housing is open.
The potentiometers on the front should only
be adjusted using a screwdriver, which is
safely isolated from the voltage at the input.
For applications with high operating
voltages, ensure sufficient distance or
insulation and provide shock protection.
Safe and error-free operation of this device
can only be ensured if transport, storage, and
assembly are carried out correctly and
operation and maintenance are carried out
with care.
When operating this electric measuring
transducer, the national regulations
(e.g., in Germany, VDE 0100 "Conditions for the
Erection of Electrical Power Installations with
Nominal Voltages Below 1000 V") must be
observed during the installation and selection of
the electrical conductors.
Connection
terminal
block
Description
1(12) N/C contact1
1Only for MCR-S-...-SW-DCI(-NC)
2(11) Center contact1
3(14) N/O contact1
4Not used
510 A input2
2Only for MCR-S-1-5-(-SW)-DCI(-NC)
65 A input2
71 A input2
8Reference ground for 1, 5, and 10 A input2
9Current output
10 Voltage output
11 Reference ground for current or voltage
output
12 Reference ground for current or voltage
output
13 Operating voltage (+24 V DC)
14 Reference ground for operating voltage
15 Transistor output1
16 Reference ground for transistor output1
W?
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 12
6.4 Startup
Before starting up the measuring transducer, please ensure
that the module configuration data matches the measuring
requirements. The configuration data for a preconfigured
device can be found on the right hand side of the housing.
If you are using an unconfigured transducer, there is a
standard configuration which can be found in the order keys
on page 6 and page 9. If the desired configuration does not
match the label on the side of the housing or the standard
configuration, refer to the section below.
6.5 Configuration flowchart
Figure 2 Configuration flowchart
6.5.1 Configuration or programming
The MCR-S-...-DCI generation offers the advantage of a
choice between configuration and programming.
MCR/PI-CONF-WIN software can be used to freely program
the true r.m.s. value current transducer.
Programming is explained in the software manual. The
user-friendly configuration software runs under all popular
Windows operating systems.
In addition to programming, modules can be parameterized
using DIP switches and potentiometers.
The rest of this section deals with configuration:
6.5.2 Opening the housing
Release the locked upper part of the housing on both sides
with the help of a screwdriver. The upper part of the housing
and the electronics can now be pulled out approximately
3 cm.
Figure 3 Opening the housing
Configuration
or
programming
Threshold value
output
Ready for operation
Programming
Configuration via DIP switches
No
Yes
Software
package
Opening the housing
Configuration of the input
current range and
measuring process
Configuration of the
analog output
Fine adjustment of
the measuring
Configuration of the
threshold value output
The transducer must not be started up when the
housing is open.
5678
1234
N
SW
MC
R-S-1-5-UI-SW-DCI
RELAIS OUT
IN
12 1114 NC
10A 5A 1A
MCR-S-1-5-UI-SW-DCI
Art.-Nr.: 28 14 65 0
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 13
Figure 4DIP switches
Setting DIP switch 10 to configuration mode (DIP switch 10
to "OFF") switches all potentiometers to "active".
6.5.3 Configuration of the input current range and
measuring process
(Rough setting via DIP switches)
Use DIP switch 9 to select the measuring process (true
r.m.s. value or arithmetic average value).
True r.m.s. value: The true r.m.s. value of an AC current
corresponds by definition to the steady-state value that
results from the instantaneous values of this current. This
steady-state value generates the same thermal work in an
ohmic resistor as a DC current of identical magnitude. The
term "true r.m.s. value" simply indicates that distorted and
pulsating currents are also measured.
Arithmetic average value: The arithmetic average value is
used to measure DC currents or to filter a DC portion from a
pulsating current. Using the arithmetic average value on a
symmetrical AC current would result in the measured value
being "0".
The arithmetic average value can be used to make bipolar
DC currents available as analog standard signals at the
output.
DIP Description
10 Configuration via DIP switches/
programming via software
9Input current measurement: True r.m.s.
value/arithmetic average value
8Operating current/closed circuit current
behavior1
7Above threshold value/
Below threshold value1
1Only for MCR-S-...-SW-DCI(-NC)
6
Setting the analog output signal
5
4
3
2Setting the input measuring range
1
DIP 10 Description
OFF Configuration via DIP switches
ON Programming via software (DIP switches 1
to 9 and potentiometer settings not relevant)
DIP
10
...
1
DIP 9 Description
OFF True r.m.s. value (AC and DC without
without sign bitdetection)
ON Arithmetic average value (DC with sign
bitdetection)
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 14
MCR-S-1-5-...DCI: Optimum use of the measuring
ranges
MCR-S-10-50-...DCI: Optimum use of the measuring
range
6.5.4 Configuration of the analog output
6.5.5 Configuration of the Threshold Value Output
The relay and transistor output of the threshold value
versions (MCR-S-...-SW-DCI) are set after the input
measuring range and the analog output have been adapted.
Setting the switching threshold
The diagrams below (Figure 5 to Figure 8 on page 15)
illustrate the four possible switching behavior options for the
relay and transistor output. The various options for the
operating behavior in threshold value mode are divided
according to:
– Operating current or closed circuit current principle
– Threshold value triggered when value is below
threshold
– Value is above threshold value
If necessary, the corresponding switching behavior can be
set via DIP switch 7 and DIP switch 8.
SPAN
potentio-
meter
-25%
Nominal
range1
1The nominal range is adapted
SPAN
potentio-
meter
+25%
DIP 1 DIP 2
1 A input: Measuring range: 0 A ... 0.18 A to 0 A ...1.1 A
0 A ... 0.75 A 0 A ... 1.00 A 0 A ... 1.10 A OFF OFF
0 A ... 0.48 A 0 A ... 0.65 A 0 A ... 0.81 A OFF ON
0 A ... 0.30 A 0 A ... 0.40 A 0 A ... 0.50 A ON OFF
0 A ... 0.18 A 0 A ... 0.25 A 0 A ... 0.31 A ON ON
5 A input: Measuring range: 0 ... 0.94 A to 0 ... 5.5 A
0 A ... 3.75 A 0 A ... 5.00 A 0 A ... 5.50 A OFF OFF
0 A ... 2.43 A 0 A ... 3.25 A 0 A ... 4.06 A OFF ON
0 A ... 1.50 A 0 A ... 2.00 A 0 A ... 2.50 A ON OFF
0 A ... 0.94 A 0 A ... 1.25 A 0 A ... 1.56 A ON ON
10 A input: Measuring range: 0 ... 4.87 A to 0 ... 11 A
0 A ... 7.50 A 0 A ... 10.0 A 0 A ... 11.00 A OFF OFF
0 A ... 4.87 A 0 A ... 6.5 A 0 A ... 8.12 A OFF ON
SPAN
potentio-
meter
-25%
Nominal
range1
1The nominal range is adapted
SPAN
potentio-
meter
+25%
DIP 1 DIP 2
Measuring range: 0 A ... 9.38 A to 0 A ... 55 A
0 A ... 37.5 A 0 A ... 50.0 A 0 A ... 55.0 A OFF OFF
0 A ... 24.4 A 0 A ... 32.5 A 0 A ... 40.6 A OFF ON
0 A ... 15.0 A 0 A ... 20.0 A 0 A ... 25.0 A ON OFF
0 A ... 9.38 A 0 A ... 12.5 A 0 A ... 15.6 A ON ON
Output DIP 3 DIP 4 DIP 5 DIP 6
0 mA ... 20 mA OFF OFF OFF OFF
20 mA ... 0 mA OFF OFF OFF ON
4 mA ... 20 mA OFF OFF ON OFF
20 mA ... 4 mA OFF OFF ON ON
0 V ... 10 V OFF ON OFF OFF
10 V ... 0 V OFF ON OFF ON
0 V ... 5 V OFF ON ON OFF
5 V ... 0 V OFF ON ON ON
1 V ... 5 V ON OFF ON OFF
5 V ... 1 V ON OFF ON ON
-10 V ... 10 V ON ON OFF OFF
10 V ... -10 V ON ON OFF ON
-5 V ... 5 V ON ON ON OFF
5 V ... -5 V ON ON ON ON
DIP 7 DIP 8 Switching Behavior of Relay
and Transistor Output
See
OFF OFF Operating current-controlled
when above threshold value Figure 5
ON OFF Operating current-controlled
when below threshold value Figure 6
OFF ON Closed circuit current-controlled
when above threshold value Figure 7
ON ON Closed circuit current-controlled
when below threshold value Figure 8
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 15
Switching behavior of relay and transistor output for the current transducer
(0) = N/O contact and transistor open, N/C contact closed, LED off
(1) = N/O contact and transistor closed, N/C contact open, LED on
t1 can be set via software and potentiometer
Figure 5 Function diagram: Operating current-
controlled when above threshold value
Figure 6 Function diagram: Closed circuit current-
controlled when above threshold value
Figure 7 Function diagram: Operating current-
controlled when below threshold value
Figure 8 Function diagram: Closed circuit current-
controlled when below threshold value
t1
t1
t1
I
IN
t
t
t
t
(L)
(H)
t1
Operating
voltage UB
SW condition
Relay N/O contact
and transistor output
Relay N/C
contact
(1)
(0)
(0)
(1)
t
I
IN
t
(L)
(H)
t
t
t
t
t
t
Operating
voltage UB
SW condition
Relay N/O contact
and transistor output
Relay contact
(1)
(0)
(0)
(1)
I
IN
t
t
t
t
(L)
(H)
t
t
Operating
voltage UB
SW condition
Relay N/O contact
and transistor output
Relay contact
(1)
(0)
(0)
(1)
I
IN
t
(L)
(H)
t
t
t
t
t
Operating
voltage UB
SW condition
Relay N/O contact
and transistor output
Relay contact
(1)
(0)
(0)
(1)
olenhomelers
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 16
Fine adjustment of the measuring transducer
•Close the module after roughly setting the input current
range and preselecting the output signal.
•Connect the module to the signal lines and the
operating voltage according to the instructions in
"Electrical connection" on page 11.
When the green "POWER" LED is lit, the operating voltage
of 20 V DC ... 30 V DC is connected.
Analog Output
Figure 9 Potentiometers
ZERO and SPAN behavior (±25% each) are shown in
Figure 10 and Figure 11:
– ZERO potentiometer for zero point adjustment
– SPAN potentiometer for final value adjustment
Figure 10 Offset (ZERO) behavior
Figure 11 Final value (SPAN) behavior
When using the MCR-S-...-DCI, ensure you use
the correct signal input terminal block for your
measuring range.
Signal input
range
Signal input
terminal block
Ground terminal
block
1 A 7 8
5 A 6 8
10 A 5 8
Allow the module to warm up for 2 minutes before
starting the adjustment procedure.
9101112
56
7
1234
POWER
SWZERO
SPAN
SW
MCR-S-1-5-UI-SW-DCI
RELAIS OUT
TIME
20 0
sec
OUT
IN
12 1114 NC
10A 5A 1A
+24V GND1 SW GND1
UGND2GND2
MCR-S-1-5-UI-SW-DCI
Art.-Nr.: 28 14 65 0
OUT
[%]
IN
[%]
100
-100
100-100
SPAN +25%
SPAN -25%
11 0
-110
OUT
[%]
IN
[%]
100
-100
100-100
11 0
-110
SPAN
+25% -25%
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 17
Adjustment structure
Figure 12 Adjustment structure
•After connecting the operating voltage and signal lines,
first adjust the zero point (offset). There should be no
signal at the input (IE = 0).
•The analog output must correspond to a preselected
output signal from the table on page 14. Adjust any
inaccuracies using the ZERO potentiometer.
•To adjust the measuring range final value, a current
should be specified which is the same level as the final
value if possible. If this is not possible, one of the
following adjustment formulae should be used:
Example:
The current transducer is to be set to the following values:
Input measuring range: 0 A ... 5 A IME = 5 A
Output measuring range:0 mA ... 20 mA I0= 0 mA
IMA = 20 mA
Constant current for configuration IE= 3 A
•Adjust the calculated output current using the SPAN
potentiometer to IA = 12 mA. When the voltage output is
used, the same adjustment procedure is necessary.
Threshold value output
•Specify a current for the module, which corresponds to
the threshold value:
•Set the TIME potentiometer to "0 s" and turn the
threshold value potentiometer according to the
following instructions (see Figure 5 to Figure 8 on
page 15):
–For Figure 5: Turn the threshold value potentiometer
until the yellow "SW" LED lights up.
–For Figure 6: Turn the threshold value potentiometer
until the yellow "SW" LED goes out.
–For Figure 7: Turn the threshold value potentiometer
until the yellow "SW" LED goes out.
–For Figure 8: Turn the threshold value potentiometer
until the yellow "SW" LED lights up.
•To prevent switching behavior at the binary output level
during a brief overcurrent, a suppression time must be
set using the TIME potentiometer. If the increased
current is present for longer than the specified
suppression time, the preselected switching behavior
becomes active. The available setting range is 0 to
20 seconds.
When the yellow "SW" LED lights up (relay and transistor
status display), the N/O contact of the PDT contact is closed
and the N/C contact of the PDT contact is opened. The
transistor output switches through.
MCR-S
A
IE
UA
IA
A
V
Operating voltage
Signal output
Signal input
UA = U0 + (––– * (UMA - U0))
IA = I0 + (––– x (IMA - I0)) IE
IME
IE
IME
an.“ Anwrwrwwmumuu‘ gag
MCR-S-...-DCI
100241_en_11 PHOENIX CONTACT 18
7 Software package (adapter)
As an alternative to setting via DIP switches, the module can
be programmed using the MCR/PI-CONF-WIN
configuration software (Order No. 2814799).
Software features
– All configuration parameters can be entered in the
computer
– The parameters entered in the computer can be saved
to the measuring transducer
– The parameters available in the module can be
exported
– The parameters can be saved to a drive of your choice
–A side-panel label can be created
– The programmed module parameters can be printed
– Bar graph display
– Monitoring function
The MCR-TTL/RS232-E software adapter cable
(Order No. 2814388) can be used to connect the computer
and the current transducer. This cable has a stereo jack
connector on one end for connection to the current
transducer and a 25-pos. D-SUB female connector on the
other end for connection to a computer. For connection to
the computer, an adapter cable for the interface converter is
usually required (9-pos. D-SUB female connector to 25-pos.
D-SUB male connector, Order No. 2761295).
DUDE
MCR-S-...-DCI
100241_en_11 19
PHOENIX CONTACT GmbH & Co. KG • 32823 Blomberg • Germany
www.phoenixcontact.com
8 Application examples
8.1 Motor current measurement
Figure 13 Motor current measurement
The use of MCR-S-...-DCI modules in one or more supply phases of the motor enables what is known as "motor monitoring"
(Figure 13). The MCR current transducer can transfer corresponding standard signals about the motor load to the control
system or service personnel. The true r.m.s. value measurement process means that AC, DC, and distorted currents can be
measured. Even higher frequency currents up to 1 kHz can be acquired.
8.2 Acquisition of motor current peak loads
Figure 14 Acquisition of motor current peak loads
Large industrial motors must be overhauled and serviced at regular intervals. Installing an MCR current transducer in one
phase of the motor feed line enables pulses to be generated with the relay or transistor switching output that can be
measured using a simple meter (Figure 14). The service personnel can then use the motor starts and peak loads as a basis
to provide efficient maintenance corresponding to the number of overloads.
8.3 Lighting monitoring
MCR current transducers can be used for monitoring lighting. If the strength of the current in a circuit is above or below a
specified value after a suppressed switch-on time, there is a fault in the lighting circuit. If the lighting circuit fails, this signal
status can be passed on to another control unit and the emergency lighting can be switched on. The same method can also
be used with other power loads.
24V
MCR-S-... ⁄
$
%
+ 24V
POWER
SW
1
2
3
9
0
!
I
U
GND 2
Power
OUT
Relais
5
6
7
&
GND 1
4"
GND 2
8NC
1 A 14
5 A 11
10 A 12
GND 1
OUT
30
sec
0
TIME
SW
OFFS ET
GAIN
SW
N
L1
Frequency inverter
Mains voltage
Controller
MC R-S-... ⁄
$
%
+ 24V
POWER
SW
1
2
3
9
0
!
I
U
GND 2
Power
OUT
Relais
5
6
7
&
GND 1
4"
GND 2
8NC
1 A 14
5 A 11
10 A 12
GND 1
OUT
30
sec
0
TIME
SW
OFFSET
GAIN
SW
24V
0 1 2 3
L1
N
Mains voltage
Maintenance
interval counter
